1. INSTALLATION
INSTALLER
Polypropylene venting listed to ULC-S636
Diameter Length Brand Part Number Description
3/5” (80/125mm) Z-Dens 2ZDACLC3335 Adaptor Collinear to Concentric
3” (80mm) 12” (305mm) Z-Dens 2ZDP312 Single Wall Pipe
24” (305mm) Z-Dens 2ZDP324 Single Wall Pipe
36” (305mm) Z-Dens 2ZDP336 Single Wall Pipe
72” (305mm) Z-Dens 2ZDP372 Single Wall Pipe
Z-Dens 2ZDE345 Single Wall 45° Elbow
Z-Dens 2ZDE387 Single Wall 87° Elbow
Z-Dens 3PPS-CDC Single Wall Condensate Drain
Z-Dens 3PPS-TCDC Single Wall Tee w/ Drain Cap
3” (80mm) 12” (305mm) PolyPro 3PPS-12C Single Wall Pipe
36” (305mm) PolyPro 3PPS-36C Single Wall Pipe
72” (305mm) PolyPro 3PPS-72C Single Wall Pipe
PolyPro 3PPS-E45C Single Wall 45° Elbow
PolyPro 3PPS-E90C Single Wall 90° Elbow
PolyPro 3PPS-CDC Single Wall Condensate Drain
PolyPro 3PPS-TCDC Single Wall Tee w/ Drain Cap
