Radio Shack Telephone Interface II System Manual

Lebw
3
Inchej
of
CflWe
Strain Ftalitf
Bracket
HflixJ Disk
Expansion
Connsctor
Ac«ss
Panel
Notches for
FJoppy Diskatta
Cablei
Expansion
Connector
1.
Remove
the
access panel by
loosening
the
thumbscrews.
2.
Attach -he
cables
[hat are
included
with your
expansion
unit
to
the
appropriate
connector.
Connect
the
34-pin
Secondary
Hard
Disk
Expansion
Cable
Connector to
the
34-pin snap-in
connector on
the
edge of the
P.C.
board.
Also
connect
[he
20*pin
Data
Cable Connector
to the
20
-pin
snap-in
connector
on the edge of
f
he P.C.
board.
If
you are connecting
a Fbopy Disk
Expansion
Unit
attach [he
connector
on one end of
The cable
to the 50-pin
connector
on
the chassis.
Connect the
other
end
ot
the
cable
to the
Expansion Unit.
Position
all the
Built-in
Hard Disk
internal
connectors
so that
the
cables
exit from the
bottom.
3.
Remove
the
strain relief
^rackets
from the
access
panel. Run
the
cables
downward
through the
,:
strain
reliefs
11
nearest
to
the
cables,
leaving
about
8
inches
of
cable
between the
strain
relief
and the
computer.
4.
Replace
the
strain relief
brackets
and run the
cab
!
es through
the
notch in the
computer
base.
5.
Replace
the
access
panel
and tighten
the
thumbscrews.
Also,
the Hard
Disk
Drives
in
your
System
must
always contain
a
Line Terminator.
Check
with your
Radio
Snack
Computer
Center
for
details.
77
