12
4. If necessary, turn
RF.GAIN
clock-
wise to increase the signal sensi-
tivity.
To turn off the TRC-488, turn
VOLUME
counterclockwise until you hear it click.
TRANSMITTING
We recommend you spend some time
receiving transmissions before you try
to transmit a message yourself.
Follow these steps to transmit.
1. Set the mode selector to
CB
.
2. Slide
CH9/OUT
to
OUT
.
3. Turn
CHANNEL
to the desired
channel.
4. Hold the microphone 2 or 3 inches
from your mouth, then press and
hold down the microphone talk
button and speak into the micro-
phone in a normal voice. The red
TX indicator lights.
Note
: Do not speak too loudly
when transmitting. It does not
make your signal any stronger,
and might distort your transmis-
sion.
5. When you finish transmitting,
release the microphone talk but-
ton. You can now receive trans-
missions.
6. To turn off the TRC-488, turn
VOL-
UME
counterclockwise until you
hear it click.
(illus)
(illus)
(illus)
