6
CONNECTIONS
CONNECTING THE
MICROPHONE
1. Make sure the pins on the micro-
phone cable’s plug are aligned
with the holes in the CB’s
MICRO-
PHONE
jack on the CB’s left side
and insert the plug into the jack.
2. Slide the microphone onto the
microphone holder.
To disconnect the microphone cable,
press and hold down the small tab on
the microphone plug, then pull out the
plug.
Caution
: Never pull on the micro-
phone cable.
CONNECTING AN
OPTIONAL EXTERNAL
SPEAKER
You can connect an external speaker
to the CB.
Notes
:
• You must use an 8-ohm speaker
capable of handling up to 5 watts
of power (such as Radio Shack
Cat. No. 21-549).
• The speaker’s cable must have a
1
/
8
-inch plug.
To connect an external speaker, sim-
ply plug the speaker’s cable into the
CB’s
EXT
jack.
Note
: When you connect an external
speaker, the CB’s internal speaker dis-
connects.
(illus)
(illus)
(illus)
(illus)
