Radio Shack TRS-80 Model 4 Technical Reference Manual

84
Parts List, Model 4 Computer, #26-1067/8/9
Item Qty Description Mfgr’s PN RS Part No
33 1 Cable, Ground 8709193
34 1 Ground, Main 8709161
35 1 Clip, Tinnerman 8559031
36 1 Cable Assembly, CRT 8709369
for Models 26-1068/1069
for Model 26-1067 8709286
37 5 Clip, Tinnerman -------
38 1 Bracket, Support 8729055
39 1 Strain Relief, Power Cord 8559014
40* 1 FDC PCB Assembly 8858060 or
8858160
41* 1 Flat Cable Assembly 8459020
42* 1 Cable Assembly, Disk Drive 8709154
43 1 Shield, CRT PCB Assembly 8539014
44 2 Tab, Grounding 8529020
45 1 Shield, Disk Drive Top
(used on 26-1069 only)
8729175
46 1 Shield, Mylar 8539015
47 1 Cable Assembly, DC Power 8709367
for 26-1068/9
for 26-1067 8709178
48 3 Screw, #8-32 x 3/4” PPH Blk 8569047
49 8 Screw, #6-32 x 1/2” PPH 8569046
50 4 Screw, #6 x 1/4” Plastite 8569077
51 6 Screw, #8-32 x 1/2” 8569140
52 4 Screw, #6-32 x 1/4” 8569098
53* 12 Screw, #6 x 3/8” Washer 8569128
54 4 Screw, Chassis Mounting 8569077
55 5 Screw, #8 x 1” 8569095
56 2 Screw, #8-32 x 1” 8569084
57 2 Screw, #6 x 3/8” 8569047
58* 2** Disk Drive Assembly 8790112
59 2 Screw, #6-32 x 1/4” 8569098
60 1 Washer, #6 Internal Star 8589043
61 2 Nut, #6 Hex 8579014
62* 3 Standoff, Power Supply 8589079
63 1 Switch, DPST (ON-OFF) 8489030
* Not Used On 26-1067 Computer
** Qty Of 1 On 26-1068 Computer
