D2412 Terminal Quick Reference
Terminal Description
1,2 16.5VAC 16.5 VAC Connect D1640, 16.5, 40VA Transformer for primary power.
3
∇
Earth Ground Connect to earth ground. A cold water pipe or grounding rod is
preferred. Do not connect to telephone or electrical ground.
4 +Alrm + Alarm Output Continuous positive output provides 1.85 Amps at 10.2 10 13.9 VDC.
Protected against overcurrent by self resetting device.
5 Alrm- - Alarm Output Switched negative output for steady or pulsed (temporal code 3) alarm
output.
6 Data Data Data for keypads and point expanders.
7 +Aux + Aux Power Positive output for continuously powered devices, 1.0A at 10.2 to 13.9
VDC. Protected against overcurrent by self resetting device.
8 Aux- - Aux Power Negative (common) for Aux Power and Relay Outputs.
9 Ext1 External Relay 1 Connect D133 or D134 relay for Form C Dry Contact.
10 Ext2 External Relay 2 Connect D133 or D134 relay for Form C Dry Contact.
11 1+ Positive Point 1 Positive Power for Point 1. Switched for sensor reset. Use for approved
2 wire smoke or glass break detectors.
12 1- Negative Point 1 Negative Power for Point 1.
13 Com Common Common for Point 2.
14 2 Point 2 Input for Point 2.
15 3 Point 3 Input for Point 3.
16 Com Common Common for Points 3 and 4.
17 4 Point 4 Input for Point 4.
18 5 Point 5 Input for Point 5.
19 Com Common Common for Points 5 and 6.
20 6 Point 6 Input for Point 6.
21 T Tip Tip of incoming phone line.
22 T1 Tip1 Tip of phone line to premises phone.
23 R1 Ring1 Ring of phone line to premises phone.
24 R Ring Ring of incoming phone line.
