26
RWSERIES
6.2 CHANGING THE ENGINE OIL
WARNING!
Used motor oil can cause skin irritations if left in long-term contact
with skin. Thoroughly wash off used oil as soon as possible with soap
and water.
Do not dispose of used oil in drains or on soil. Local service shops
provide environmentally-friendly disposal methods.
Drain the oil rapidly and completely on a level surface while the engine is still warm.
1. Stop the engine and remove oil dipstick.
2. Place a pan under the engine to catch the oil.
3. Remove the oil drain bolt and allow the oil to completely drain into the
pan by tilting the pressure washer to the side to empty the oil from the
crankcase.
4. Return the pressure washer to a level position and reinstall drain bolt. Fill
the engine with fresh oil (SAE 10W-30 4 Cycle Engine Oil) up to the
maximum mark on the dipstick without threading it back in. Do not overfill
oil reservoir. Use a funnel to prevent spillage.
5. Reinstall the oil dipstick and tightly fasten.
Note
Oil capacity (400mL)
SAE 10W-30 oil is recommended for general use.
DO NOT OVERFILL.
Oil Drain Bolt
Oil Drain Pan
