4-channels high level, 2-channels low level, built-in Bluetooth
Dynamic Range
100dB
S/N Ratio (RCA)
98dB
THD
0.05%
Freq. Response
20Hz~20kHz
Input Impedance
RCA: 20kΩ; High level: 18Ω
Low Level Output Impedance
51Ω
Input Range (max)
Output Range (max)
RCA: 6Vpp; High level: 40Vpp
Operating Temperature
Supply Voltage
DC 9V~16V
REM Input
High level input FL+/FL- or ACC on function (optional)
REM Output
+12V starting voltage (0.2A)
Standby Power
≤0.1W
Net Weight
Approx.0.93kg
Dimension
178 (L) *150 (W) *40 (H)mm
Functional Parameters
Technical Specifications
6-channels low level, power: 4×70W
Gain range: mute, -59.9dB~0.0dB
31-band equalizer
1. Frequency range: 20Hz~20kHz, resolution: 1Hz
2. Q value (slope): 0.404~28.852
3. Gain: -12.0dB~+12.0dB, resolution: 0.1dB
Each channel has an independent multi-stage filter
1. Types: Linkwitz-Riley, Butterworth and Bessel
2. Crossover point: 20Hz~20kHz, resolution: 1Hz
3. Slope setting: 6dB/Oct~48dB/Oct and OFF
Part 3: Product Parameters
Peak Power
4×70W
-20～60℃
7
RCA: 6Vpp; High level: 26Vpp
Input Signal Type
Output Signal Type
Output Signal Gain
Output Signal EQ
Output Signal
X-Over
Output Phase and
Time Alignment
Scene Operation
Phase and delay adjustments are available for each output
channel, parameter range
Phase: in-phase or reverse-phase
Time: 0.000~15.000ms, 0~205cm, 0~519 inch
The machine can save 6 preset music scenes
