Technical Specifications Germanium Two
• Performance amplifier with integrated high-current MOSFET-switch power supply
• Inverted Output stages for performance coupling during mono-bridged mode
• Output stage 2 Ω stable, bridge and tri-mode capable
• Amplifier design for minimal noise
• Reversible safety switch-off with thermal monitoring
• Safety switch-off with DC current to loudspeakers
• Safety switch-off for loudspeaker short-circuit and loudspeaker under impedance
• Integrated flat fuse 2 x 25 A in accordance with DIN-standard, replaceable from outside
• Soft start remote muting for suppression of switch-on peaks
• Low power requirements for remote-muting electrical circuits
• Palladium-plated 35 mm² power and 10 mm² loudspeaker connection
• High-tech semi-SMD built structure with low coupling wiring
• Interference-proof certified by CE
Technical Data
Output Power Stereo 4
Ω
2 x 140 Watt rms
Output Power Stereo 2
Ω
2 x 215 Watt rms
Output Power Mono 4
Ω
1 x 430 Watt rms
Total Harmonic Distortions THD+N <0.02 %
Signal-to-Noise Ratio S/N >96 dBA weighted
Frequency Response -3 dB 1.5 Hz – 50 kHz
Input Sensitivity Level In 250 mV –76 V
Input Impedance Level In
>10 k
Ω
Connection Impedance Stereo
2 x 4
Ω
/ 2 x 2
Ω
possible
Connection Impedance Mono
1 x 8
Ω
/ 1 x 4
Ω
possible
Connection Impedance Tri-Mode (Woofer + Satellite)
1 x 4
Ω
+ 2 x 4
Ω
Tri-Mode
Damping Factor
> 200 at 4
Ω
Operating Voltage 11 V - 16 V DC
Input Power Max. @ 14.4 V 48 A at 1% THD
Idle Input Power without Signal 0.7 A
Temperature Monitoring heatsink 80°C Power Down
Short-Circuit Protection – Overload Immediate Power Down
Soft start-Muting On / Off 1s Delay
Dimensions: W x H x D 420 x 55 x 235 mm
Weight 4,9 Kg
Approval CE
Active Controls:
High-pass / Subsonic 15 Hz – 500 Hz, 12 dB/Oct.
Low-pass 50 Hz – 5 kHz, 12 dB/Oct.
Band-pass 15 Hz – 5 kHz, 12 dB/Oct.
Phase Shifter 0° - 180° Infinitely Variable
