Table of Contents iPaul 2.400
User Safety Notice 4
Technical Data 6
Technical Specifications 6
Front View and Controls 7
„Controls“ 7 Figure 1
Installation 8
Remote Connection 9
Switching On / Control Function with LED 9
Amplifier „LOW INPUT“ 10
Output „LINE OUT“ for Subsequent Amplifiers 10
Remote Control 10
Bass Boost 10
„Cable Diagram: Amplifier, Radio, Loudspeaker“ 11 Figure 2
Broadband Mode 12
Broadband Mode Frequency Response 12 Figure 3
High-pass Mode 13
High-pass Mode FRONT Frequency Response 13 Figure 4
Low-pass Mode 14
Band-pass / Low-pass Mode Frequency Response 15 Figure 5
Bandpass Mode 15
Loudspeaker Connection Stereo 16
16 Figure 6
Loudspeaker Connection Mono-Bridged 17
17 Figure 7
Loudspeaker Connection Tri-Mode 18
18 Figure 8
Power Provision Indications 19
Determining „Central Ground“ 19
„Principal Connection Diagram: Central Ground“ 21 Figure 9
Warranty Terms and Conditions 22
This package contains:
- iPaul 2.400 amplifier
- Mounting screws
Dear Valued Customer,
We congratulate you on your purchase of this superior product and thank you for placing your trust in Rainbow.
We have developed this installation manual with consideration to variations in automobile mechanical and
acoustical characteristics. Nevertheless, mistakes can occur. We would greatly appreciate your bringing any
problems you encounter within to our attention.
Sincerely,
Your Rainbow Team
