Technical Data iPaul 2.400
• Performance amplifier with integrated high-current MOSFET-switch power supply.
• Inverted Output stages for performance coupling during mono-bridged mode.
• Output stage 2 Ω stable, bridge and tri-mode capable.
• Amplifier design for minimal noise.
• Reversible safety switch-off with thermal monitoring.
• Safety switch-off with DC current to loudspeakers.
• Safety switch-off for loudspeaker short-circuit and loudspeaker under impedance.
• Integrated flat fuse 2 x 25 A in accordance with DIN-standard, replaceable from outside.
• Softstart remote muting for suppression of switch-on peaks.
• Low power requirements for remote-muting electrical circuits.
• Palladium-plated 25 mm² power and 10 mm² loudspeaker connection.
• High-tech semi-SMD built structure with low coupling wiring
• Interference-proof certified by European E-Norm.
Technical Data
Output Power Stereo 4 Ω
2 x 130 Watt rms
Output Power Stereo 2 Ω
2 x 200 Watt rms
Output Power Mono 4 Ω
1 x 400 Watt rms
Total Harmonic Distortions THD+N <0.04 %
Signal-to-Noise Ratio S/N >95 dBA weighted
Frequency Response -3 dB 10 Hz – 35 kHz
Input Sensitivity Level In 250 mV – 6 V
Input Impedance Level In
10 kΩ
Connection Impedance Stereo
2 x 4 Ω / 2 x 2 Ω possible
Connection Impedance Mono
1 x 8 Ω / 1 x 4 Ω possible
Connection Impedance Tri-Mode (Woofer + Satellite)
1 x 4 Ω + 2 x 4 Ω Tri-Mode
Damping Factor
> 200 at 4 Ω
Operating Voltage 11 V - 16 V DC
Input Power Max. @ 14.4 V 48 A at 1% THD
Input Power Remote 8 mA
Idle Input Power without Signal < 0.4 A
Temperature Monitoring heatsink 70°C Power Down
Short-Circuit Protection – Overload Immediate Power Down
Softstart-Muting On / Off 1s Delay
Dimensions: W x H x D 355 x 60 x 250 mm
Weight 4,5 Kg
e-Approval No. E8 10R-09156
Active Controls:
High-pass / Subsonic 15 Hz – 500 Hz, 12 dB/Oct.
Low-pass 50 Hz – 5 kHz, 12 dB/Oct.
Band-pass 15 Hz – 5 kHz, 12 dB/Oct.
Phase Shifter 0° - 180° Infinitely Variable
Remote Control (5m Cable) Level and Phase Infinitely Variable
