8
1 = Power connection (–) minus, body and/or central ground.
2 = Remote connection of CD-radio.
3 = Power connection (+) plus, only over fuse.
4 = Flat fuse 2 x 25A in accordance with DIN-standard, replaceable from outside Replace only with like kind!
5 = Connection for external thermostat module (optional) and fan module (optional).
6 = Loudspeaker connection.
7 = Input socket „LOW INPUT“ for signal input of CD-radio.
8 = Signal output „LINE OUT“ for subsequent amplifiers
9 = Remote output for remote control
10 = Switch for high-pass or band- / low-pass operation
11 = Bass Boost
12 = Connection for peak performance coupling module (optional)
13 = Function control: blue logo = amplifier in operation, flashing logo = protection mode.
14 = „GAIN“ control for adjustment of input sensitivity for „LOW INPUT“
15 = Control for phase shifter
16 = Control for cut-off frequency low-pass
17 = Control for cut-off frequency high-pass
Installation
Fasten amplifier to a suitable, well-ventilated location in the vehicle, if possible to the auto body, with included
sheet metal screws and insulated washers.
The amplifier’s heatsink can get very hot, making sufficient distance to temperature sensitive parts absolutely
necessary.
Caution: Clamp the negative pole of the battery before working on connections. This work requires expertise
and should be performed with careful consideration to the relevant safety regulations.
Before connecting the power supply and loudspeaker cables all screws on the amplifier terminal block must be
unscrewed in an upward direction, so that the screws do not obstruct the path of the cables. Under no circumstances
should screws be completely unscrewed, however.
Caution: Important Safety Notice Concerning Risk of Fire and Injury.
Unscrewing or turning of the screws on the amplifier terminal block during active amplifier operation
(amplifier is performing) is not permitted, as the risk of a short circuit between the screwdriver and the
heatsink cannot be excluded, thus making extreme damage to the amplifier or car, or a burn injury
caused by the electrical current on the screwdriver, unavoidable.
Drilling out the amplifier terminal block for the purpose of cross-section extension for cable insertion
can cause damage to the electronics and will result in an immediate voiding of the warranty.
