Rainbow iPaul 4.300 - English

3
Table of Contents iPaul 4.300
User Safety Notice 4
Technical Data 6
Technical Specifications 6
Front View and Controls 7
„Controls“ 7 Figure 1
Installation 8
Remote Connection 9
Switching On / Control Function with LED 9
„LOW INPUT“ Connection: Amplifier 10
Output „LINE OUT“ for Subsequent Amplifiers 10
Remote Control 10
„Cable Diagram: Amplifier, Radio, Loudspeaker“ 11 Figure 2
Broadband Mode FRONT & REAR 12
Broadband Mode Frequency Response 12 Figure 3
High-pass Mode FRONT & REAR 13
High-pass Mode FRONT Frequency Response 13 Figure 4
High-pass Mode REAR Frequency Response 14 Figure 5
Low-pass Mode REAR 14
Low-pass Mode REAR Frequency Response 15 Figure 6
Bandpass REAR Mode 16
Loudspeaker Connection Stereo 16
17 Figure 7
Loudspeaker Connection Mono-Bridge 17
18 Figure 8
Loudspeaker Connection Recommendation 18 Figure 9
Loudspeaker Connection Tri-Mode 19
19 Figure 10
Power Provision Indications 20
Determining „Central Ground“ 20
„Principal Connection Diagram: Central Ground“ 22 Figure 11
Warranty Terms and Conditions 23
This package contains:
- iPaul 4.300
- Mounting screws
Dear Valued Customer,
We congratulate you on your purchase of this superior product and thank you for placing your trust in Rainbow.
We have developed this installation manual with consideration to variations in automobile mechanical and
acoustical characteristics. Nevertheless, mistakes can occur. We would greatly appreciate your bringing any
problems you encounter within to our attention.
Sincerely,
Your Rainbow Team
