In this mode of operation all linear frequencies from 10 Hz to 35 kHz are processed and amplified without
preference. Frequency separation takes place exclusively in the passive crossovers of the respective loudspeaker
systems. This mode of operation is therefore suitable for all kinds of loudspeakers and loudspeaker systems in
which frequency separation occurs via passive crossovers.
• Set „X-OVER“ (14) switch FRONT to „FULL“ in order to receive a broadband signal on the front channels.
• Set „X-OVER“ (12) switch REAR to „FULL“ in order to receive a broadband signal on the rear channels.
Figure 3: Frequency Response for FRONT or REAR Channels in Broadband Mode
