Pro2-Series 3D Printer
/ Quick Start Guide
F. Start First Print
The Pro2/Pro2 Plus units are preleveled in the
factory, but we recommend verifying that the
leveling has not changed during shipping.
First, home the X/Y Axis by selecting the
"home" button, then Z axis "home" button.
If the homing procedures complete without
issues, reposition the print head.
Select "10mm" for "Move Steps" and move X to
50mm, Y to 10mm.
1
Please use the feeler gauge to check the
distance between nozzle and printing platform.
The optimal distance between is 0.2mm.
The best condition of this is that you can feel a
little friction when you slide the feeler gauge
into the gap.
2
0.2mm
The distance between the nozzle and the
printing platform can be adjusted by turning the
thumb screw on the left-front corner of the
Z-plate, the higher the screw stands out, the
further the distance between the nozzle to the
printing platform gets.
3
Closer Further
Feeler Gage
