Raisecom ISCOM5508-GP User Manual

Raisecom
ISCOM5508-GP (A) Hardware Description
2 1BComponents
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
15
2.5.3 Interfaces
There are 10 interfaces on the WDFA4 subcard.
Table 2-15 lists interfaces on the WDFA 4 subcard.
Table 2-15 Interfaces on the WDFA4 subcard
Interface Type Usage
IN SC/APC 1550 nm CATV service inputs
OLT LC/UPC 1310 nm/1490 nm data service inputs
COM LC/APC
1310 nm/1490 nm/1550 nm wave multiplexing
service outputs
USB – For device management and maintenance
2.5.4 LEDs
There is 1 LED on the WDFA4 subcard.
Table 2-16 lists the LED on the WDFA subcard.
Table 2-16 LED on the WDFA4 subcard
LED Status Description
RUN Green/Red Power LED

Green: the power supply is working properly.

Red: the power supply is working improperly.
2.5.5 Technical specifications
Table 2-17 lists physical technical specifications of the WDFA4 subcard.
Table 2-17 Physical technical specifications of the WDFA4 subcard
Item Description
Dimensions 129.4 mm (Width) × 243.4 mm (Depth) × 19.8 mm (Height)
Weight 0.55 kg
Power consumption ≤ 20 W
Table 2-18 lists optical amplification technical specifications of the WDFA4 subcard.
