Raisecom
ISCOM5508-GP (A) Hardware Description
3 2BFiber and cables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
32
Item Description
Length
The letter D indicates the length, which is customized. For example, if
the customer requires a 3-meter cable, it is named POL-DC-
unstripped/stripped-1.0 mm
2
-3m/RoHS.
3.5 AC power cable
3.5.1 Introduction
The AC power cable supplies 110/220 VAC power from the power souring equipment to the
power interface on the RPA0601 module of the ISCOM5508-GP, and then transmits power to
the entire device.
Types of the AC power cable of the ISCOM5508-GP depend on different regional standards,
as shown in Table 3-10.
Table 3-10 AC power cable
Regional standard Name
European standard POL-AC-European 3-pin/C13-0.75 mm
2
-D/RoHS
American standard POL-AC-American 3-pin/C13-18AWG-D/RoHS
3.5.2 Appearance
The AC power cable which meets European standard is composed of a European French
mode 3-pin plug and a C13 connector, as shown in Figure 3-10.
Figure 3-10 European AC power cable
The AC power cable which meets American standard is composed of an American 3-pin plug
and a C13 connector, as shown in Figure 3-11.
Figure 3-11 American AC power cable
