Disc Wheels
Type
Nut
Stud
Size
Hex
Size
Torque
Ft Lbs
Torque
Newton Meters
Cone M14 x 1.5 22 mm 120-150 160-200
Flanged M14 x 1.5 22 mm 130-160 190-220
8-Stud — Dual Rear Wheels
Dual wheels are flat-mounted and center-piloted. The lug
nuts are a two-piece assembly. When the tires are being
rotated or replaced, clean these lug nuts and add two
drops of oil at the interface between the hex and the
washer.
Oiling Location
6
WHAT TO DO IN EMERGENCIES 597
