Cavity Cartridge
Fuse
Mini
Fuse
Description
M13 20 Amp
Yellow
Main #2 Instrument
Cluster/Wireless Con-
trol Module/ITM/
Siren/Multifunction
Switch (Steering Col-
umn Module)
M14 20 Amp
Yellow
Back Up Camera (Do-
mestic Only)
M15 20 Amp
Yellow
Power Seat
Module(s)/Audio
Telematics/Daytime
Running Lights
Relay/Instrument
Cluster/Transfer Case
Module
M16 10 Amp
Red
Airbag Module
Cavity Cartridge
Fuse
Mini
Fuse
Description
M18 15 Amp
Blue
Center Stop Lamp
M19 25 Amp
Natural
Automatic Shutdown
1 and 2
M20 15 Amp
Blue
Instrument Cluster
Interior Lighting /Sw
Steering Wheel/Sw
Bank
M21 20 Amp
Yellow
Automatic Shutdown
3
M22 10 Amp
Red
Horns (Low/High) –
Right
M23 10 Amp
Red
Horns (Low/High) –
Left
M25 20 Amp
Yellow
Fuel Pump Motor/
Diesel Lift Pump – If
Equipped
7
MAINTAINING YOUR VEHICLE 657
