Unfolding
The
Load
Floor/Crew
Cab
1.
Lift
the
60/40
seat
cushion(s)
to
the
upward
position.
2.
Unfold
both
the
legs
using
the
straps.
Load
Floor
Legs
In
Stowed
Position
Load
Floor
Legs
In
Opened
Position
3
GETTING
TO
KNOW
YOUR
VEHICLE
115
116
118
