LIGHT BULBS — Exterior
Bulb Number
Quad Headlamp – Low
Beam
H11
Quad Headlamp – High
Beam
9005
Quad Headlamp – Front
Turn Signal Lamp
3157NA
Premium Headlamp –
Low Beam
HIR2
Premium Headlamp –
High Beam
9005
Premium Headlamp –
Front Turn Signal Lamp
LED (See authorized
dealer for service)
Horizontal Fog Lamp 9145
Vertical Fog Lamp 9006
Cab Roof Marker Lamps 194NA
Center High Mounted
Stop Lamp
921
Rear Cargo Lamp 921
Box Off Tail Lamps –
Stop/Turn/Tail/License
1157
Bulb Number
Plate
Box Off Tail Lamps – Back
Up
1156
Replacing Exterior Bulbs
Base Quad / Premium Bi-Halogen: Low Beam
Headlamp, High Beam Headlamp, Front Park And
Turn — If Equipped
1. Open the hood.
2. Disconnect and isolate the negative battery cable.
3. Remove the six plastic push-in fasteners that secure the
upper radiator seal to the grille support and both fender
ledges.
4. Remove the two plastic push-in rivets that secure the
upper radiator seal to the radiator.
5. Remove the upper radiator seal from the vehicle.
6. Remove the two headlamp assembly attachment screws.
324 IN CASE OF EMERGENCY
