Cavity
Maxi
Fuse
Mini Fuse Description
F17 20 Amp
Yellow
Secondary Loads,
ECM (3.0 Diesel
Engine)
F18 7.5 Amp
Brown
KL30 ECM, KL30
Main Relay Coil (3.6
Gasoline Engine)
F18 7.5 Amp
Brown
KL30 MTA, KL30
ECM, KL30 Main
Relay Coil (3.0 Die-
sel Engine)
F19 7.5 Amp
Brown
A/C Compressor
(If Equipped)
F20 30 Amp
Green
Windshield Wiper
F21 15 Amp
Blue
Fuel Pump
Cavity
Maxi
Fuse
Mini Fuse Description
F22 20 Amp
Yellow
ECM, Ignition
Coils (3.6 Gasoline
Engine)
F22 20 Amp
Yellow
ECM, Primary
Loads (3.0 Diesel
Engine)
F23 20 Amp
Yellow
ESC Valves
F24 7.5 Amp
Brown
KL15 Vacuum
pump relay coil (3.6
Gasoline Engine) —
If Equipped
F30 15 Amp
Blue
Heated Mirrors
