RAMFAN EX50Li - Operational Modes; AC Operation; Connection of Battery Pack

8 9
Connection of Battery Pack
DC Operation
• Plugtheventilatorconnectorcable(red)intothebatteryconnector.
• Settheinstallationindexonthebatterywiththecable,liningupwiththecable
connector.
• Presstheconnectorlockandrotatetheredpiececlockwise(aquarterturntotheright)
inthemostcarefulwaypossible.
• Aligntheedgeofthebatterypackwithholderundertheredlinewhereitsays,“Align
batteryEX50Li”andrmlyslidethebatteryinthedirectionofthearrowasshownin
theillustrationuntilaloudclickisheard.
Operational Modes
• InputVoltage.90-250VAC,50/60Hz
• Theventilatoriscapableofoperatingseamlesslyincountriesthatsupplyelectricityat
either120VAC/60Hzor240VAC/50Hzwithoutmanualadjustmentsbytheuser.
• Operationoutoftheselimitscandamageelectricalcomponentsandwillvoidthe
warranty.
1.ConnectthefantoanACpowersource.
2.StatusLEDLightwillautomaticallyturngreen,displayingthestatus“Ventilatoris
connectedonACPowerSupply”.
3.StarttheventilatorbyusingtheSpeedControlknobtothedesiredspeed.
 Note:Youcankeepthebatteriesontheirlocationwithoutchargingthebattery.
 BatteryIndicatorLightswillturnobecausethereisnobatterycharging
 whenventilatorisrunningonAC.
4. Whenthefanispoweredo,StatusLEDLightwillautomaticallyturnoafter1hourand
thebatteryIndicatorLightswillredisplaybatterychargelevelofeachbatterypackdetected.
Theventilatorwillbeginchargingthebatterypacksafter60minutesofidletime.
AC Operation
• Gentlypulluptheyellowhandletoremovethebatteryfromtheholder.
EX50Li
DATE 12/09/20
ITEM#
LABEL# LB9113
REVISION -
DIMS* 1.5748 x 2.25 in
MATERIAL MainStock: TEC4911 4Mil Vinyl Flex White TC Vinyl UL 50#SCK w/Permanent Adh
COLOR Black, Red
A Switched directions of arrows 06/30/20
- Label Created 08/27/19
Revision Description Date
HISTORY - LB9113
B Moved arrows down to touch red
line and moved alignment text to its
side. 12/09/20
