RAMFAN EX50Li - Storage;Transport Modes; AC Power Cord; Operating Limitations

14 15
L
R
BAT. FAULT
PUSH FOR
WAKE | STOP
PUSH FOR
MAX
AC PWR
DC PWR FAULT
NO PWR
STORAGE
MODE
MAX
Intellisense
TM
E3
LIGHTS
SPEED
Storage/Transport Modes
Lithium-ioncellmanufacturersrecommendthatbatterycellsbestoredat30%state
ofcharge(SoC)forbestlong-termhealthandstability.Further,IATA(InternationalAir
TransportAssociation)DangerousGoodsRegulations(DGR)statethatalllithium-ion
batteriesmustnotexceed30%SoCattimeofshipment.
RAMFANbattery-poweredfansbuiltwithIntellisense
TM
E3controllersareequipped
withintegrated“Storage/TransportMode”tomakeiteasytocomplywithstorage
recommendationsandtransportregulationsbyautomaticallydischarginginstalledbattery
pack(s)to30%SoC.
1.ACpowermustbedisconnectedforStorage/TransportModetobeactivated.
2.PressandholdboththeWAKE|STOPandtheMAXbuttons,togetherfor8seconds,
untilthestatusLEDlightchangestoyellowashing.
3.Onceactivated,fanwillautomaticallyturnatlowRPMuntilbatterypackreaches30%
SoC.Once30%SoCreached,fanwillturno.
Storage/TransportModecanbeinterruptedbyturningSpeedControlatanytimeduring
theoperation.
Storage/TransportModecanbeengagedwitheitherone(1)ortwo(2)batterypacks
installedonthefan.
How to activate "Storage/Transport Mode"
AC Power Cord
CORD
STORAGE
ThisbatteryfanwasdesignedtoreplacecordedACfans,optimizingcordlessoperations.
TheACpowercordisdesignedtoberemovablefortheconvenienceofthoseuserswho
choosetooperatecordless.
TheACpowerconnectorisa”Push-Pull”lockingsystemwheretheouter(blue)slidemust
bepulledback,inlinewiththecable,tosecurelyengageconnector.
• WhenACpowerisneeded,push(blue)connectoronto(black)inletonfancontroller.
Checkthatitissecurelyengaged.
• WhendisconnectingtheACpowercordfromfan,pullbackon(blue)slidetodisengage
andgentlyremove.Storeinmarkedframepositionwhennotinuse.
Pulltheplugoutitself,neverbythecordorbywigglingitoutoftheoutlet.
RAMFANlithium-ionbatterypacksaredesignedtooperateinawiderangeof
temperatures.Duetothechemistryoflithiumionbatterycells,dierentoperationallimits
applytodischargeandchargefunctionality.
• Temperaturerange(discharge):-20
o
C to +45
o
C(-4
o
Fto+113
o
F)
• Temperaturerange(charge):0
o
C to +40
o
C(32
o
Fto104
o
F)
A“coldsoaked”batterymaynotpowerafanorbeabletotakeacharge.Ifthisoccurs,
warmupcoldbatteryatroomtemperature20
o
C(68
o
F)andtryagain.
Operating Limitations
