RAMSET RAM 30 - Hookup Electrical Power; Gate Travel Adjustment

RAM 30
www.ramsetinc.com
7
RAMSET
Figure 3
HOOKUP ELECTRICAL POWER
Figure 4
Gate travel is adjusted by loosening the
limit Cams and positioning them until
proper gate travel has been achieved.
GATE TRAVEL ADJUSTMENT
Outlet
Leads
Cam
Slams
Limit
Switches
NOTE: Hookup your electrical 15 amp wires
direct to outlet.
