AM1 • 7
PARTS LIST
Please verify that the following items are in your kit before beginning
assembly.
RESISTORS
4 270 ohm [red-violet-brown] (R6,7,9,11)
2 1K ohm [brown-black-red] (R5,10)
1 2.2K ohm [red-red-red] (R1)
4 10K ohm [brown-black-orange] (R2,3,4,8)
1 5K PC mount potentiometer [marked 502] (R12)
CAPACITORS
1 220 pF disc capacitor [marked 220 or 221] (see text C9,10,16)
1 470 pF disc capacitor [marked 470] (see text C9,10,16)
1 .001 µF disc capacitor [marked .001 or 102] (see text C9,10,16)
4 .002 or .0022 µF disc capacitor [marked .002,.0022 or 2000,2200]
(C13,14, see text C9,10,16)
7 .01 µF disc capacitor [marked .01 or 103 or 10nF] (C3,5,6,7,8,11,12)
3 10 µF electrolytic capacitors (C1,2,4)
1 220 µF electrolytic capacitor (C15)
INDUCTORS
1 48 µH inductor [enameled copper wire wound on ferrite core] (L1)
1 10 µH inductor [marked 100] (L3)
1 slug tuned variable inductor [fine wire wound on plastic and
cardboard cylinder] (L2)
SEMICONDUCTORS
6 NPN transistors [marked 3904] (Q1,2,3,4,5,6)
MISCELLANEOUS PARTS AND HARDWARE
2 RCA type PC mount connectors (J1,2)
1 2.5mm power jack (J3)
1 DPDT pushbutton switch (S1)
1 AM1 printed circuit board
1 “diddle stick” plastic alignment tool
