R&S FSV3007 User Manual

Measurements and Results
R&S
®
FSVA3000/ R&S
®
FSV3000
204User Manual 1178.8520.02 ─ 01
For details on limit lines for searches, see "Peak search limits" on page 459.
Remote command:
CALCulate<n>:MARKer<m>:X:SLIMits[:STATe] on page 990
CALCulate<n>:MARKer<m>:X:SLIMits:LEFT on page 991
CALCulate<n>:MARKer<m>:X:SLIMits:RIGHt on page 991
Deactivating All Search Limits
Deactivates the search range limits.
Remote command:
CALCulate<n>:MARKer<m>:X:SLIMits[:STATe] on page 990
CALCulate<n>:THReshold:STATe on page 993
7.5.4 How to Determine the Occupied Bandwidth
The following step-by-step instructions demonstrate how to determine the occupied
bandwidth.
For remote operation, see Chapter 14.5.5.2, "Programming Example: OBW Measure-
ment", on page 790.
How to determine the OBW for a single signal
1. Press the [MEAS] key or select "Select Measurement" in the "Overview" .
2. Select the "OBW" measurement function.
The measurement is started immediately with the default settings.
3. Select the "OBW Config" softkey.
The "Occupied Bandwidth" configuration dialog box is displayed.
4. Define the percentage of power ( "% Power Bandwidth" ) that defines the band-
width to be determined.
5. If necessary, change the channel bandwidth for the transmission channel.
6. To optimize the settings for the selected channel configuration, select "Adjust Set-
tings" .
7. Start a sweep.
The result is displayed as OBW in the marker results.
How to determine the OBW for a multicarrier signal using search limits
1. Press the [MEAS] key or select "Select Measurement" in the "Overview" .
2. Select the "OBW" measurement function.
3. Select the "OBW Config" softkey.
Occupied Bandwidth Measurement (OBW)

R&S FSV3007 Specifications

General

Frequency Range	10 Hz to 7 GHz
Resolution Bandwidth	1 Hz to 10 MHz
Analysis Bandwidth	Up to 40 MHz
Maximum analysis bandwidth	40 MHz
Phase Noise	-111 dBc (1 Hz) at 1 GHz, 10 kHz offset
Amplitude range	-150 dBm to +30 dBm
Weight	17 kg (37.5 lb)
Displayed average noise level (DANL)	-165 dBm/Hz
Input VSWR	1.5
Display	10.1" touchscreen
