Measurements and Results
R&S
®
FSVA3000/ R&S
®
FSV3000
261User Manual 1178.8520.02 ─ 01
Remote command:
CALCulate<n>:ESPectrum:PEAKsearch:MARGin on page 821
Details
Configures how detailed the list in the Result Summary is.
On Includes all detected peaks (up to a maximum defined by "Peaks per Range" ).
Off Includes only one peak per range.
Remote command:
CALCulate<n>:ESPectrum:PEAKsearch:DETails on page 833
Peaks per Range
Defines the maximum number of peaks per range that are stored in the list. Once the
selected number of peaks has been reached, the peak search is stopped in the current
range and continued in the next range. The maximum value is 50.
Remote command:
CALCulate<n>:PEAKsearch:SUBRanges on page 834
Save Evaluation List
Exports the evaluation list of the Spurious Emissions measurement to an ASCII file for
evaluation in an external application. If necessary, change the decimal separator for
evaluation in other languages.
Define the file name and storage location in the file selection dialog box that is dis-
played when you select the "Save" function.
For details, see "How to Save the Spurious Emissions Evaluation List" on page 262.
Remote command:
MMEMory:STORe<n>:LIST on page 1085
FORMat:DEXPort:DSEParator on page 1060
7.7.5 How to Perform a Spurious Emissions Measurement
The following step-by-step instructions demonstrate how to perform spurious emis-
sions measurements.
For remote operation, see Chapter 14.5.7.7, "Programming Example: Spurious Emis-
sions Measurement", on page 835.
1. Press the [MEAS] key, then select the "Spurious Emissions" measurement.
2. Define the span of the signal to be monitored in the general span settings.
3. Select the "Overview" softkey, then select the "Spurious Setup" button.
The "Spurious Emissions" dialog box is displayed.
Spurious Emissions Measurement
