R&S FSV3007 User Manual

Network and Remote Operation
R&S
®
FSVA3000/ R&S
®
FSV3000
721User Manual 1178.8520.02 ─ 01
The most commonly used folders on the instrument are displayed, for example
those that contain user data, as well as the top-most My Computer folder, from
which you can access all other folders on the instrument.
3. To download a file from the R&S FSV/A, select the file from the displayed folders
and then select "Download File".
4. To upload a file to the R&S FSV/A:
a) From the displayed folders in the web browser window, select the folder on the
R&S FSV/A to which you want to copy a file.
b) Under "File to Upload", select "Browse" to open a file selection dialog box and
select the required file on the PC.
c) Select "Upload" to copy the file from the PC to the defined folder on the
R&S FSV/A.
13.6.6 How to Deactivate the Web Browser Interface
If you want to prevent other users in the LAN from accessing or operating the
R&S FSV/A via its LXI web browser interface, you must deactivate this function. Note
that after a firmware update the function is automatically active again until you
deactivate it manually.
To deactivate the LXI web browser interface
1.
Select the "Windows" icon in the toolbar to access the operating system.
2. In the "Start" menu, select "Control Panel".
3. Select "System and Security" > "Administrative Tools".
4. From the list on the right, select "Services".
5. From the list of local services, select "R&S TightVNC Server".
How to Set Up a Network and Remote Control

R&S FSV3007 Specifications

General

Frequency Range	10 Hz to 7 GHz
Resolution Bandwidth	1 Hz to 10 MHz
Analysis Bandwidth	Up to 40 MHz
Maximum analysis bandwidth	40 MHz
Phase Noise	-111 dBc (1 Hz) at 1 GHz, 10 kHz offset
Amplitude range	-150 dBm to +30 dBm
Weight	17 kg (37.5 lb)
Displayed average noise level (DANL)	-165 dBm/Hz
Input VSWR	1.5
Display	10.1" touchscreen
