Measurements and Results
R&S
®
FSVA3000/ R&S
®
FSV3000
242User Manual 1178.8520.02 ─ 01
7.6.6.2 How to Save SEM Result Files
The Result Summary from an SEM measurement can be saved to a file, which can be
exported to another application for further analysis, for example.
For details on the file format of the SEM export file, see Chapter 7.6.8.2, "ASCII File
Export Format (Spectrum Emission Mask)", on page 250.
1. Configure and perform an SEM measurement as described in Chapter 7.6.6, "How
to Perform a Spectrum Emission Mask Measurement", on page 237.
2. In the "Overview" , select the "Analysis" button.
3. If necessary, change the "Decimal Separator" to "COMMA" for evaluation in other
languages.
4. Select the "Save" button.
5. In the file selection dialog box, select a storage location and filename for the result
file.
6. Select the "Save" button.
The file with the specified name and the extension .dat is stored in the defined
storage location.
7.6.7 Measurement Example: Multi-SEM Measurement
The following measurement example demonstrates an SEM measurement for a signal
with multiple sub blocks.
A programming example demonstrating a SEM measurement in a remote environment
is provided in Chapter 14.5.6.11, "Example: SEM Measurement", on page 823.
Test setup:
Spectrum Emission Mask (SEM) Measurement
