12
8 ea. 1/4”
Washers
8 ea. 1/4” x
1/2” Screws
8 ea. 1/4”
Nuts
Step 1
1) Attach the two red plates to the burner tubes using 1/4” x 1/2”
screws (8 ea.), 1/4” flat washers (8 ea.) and 1/4” nuts (8 ea.).
You will need to bend the Gas Flex Lines so that the Red Plate
will reach each burner tube. Note: If it becomes necessary to
remove the Flex Line from the Red Plate, be sure to tighten the
Gas line securely to prevent any gas leaks.
9
Step 1
1) Attach the two red plates to the burner tubes using 1/4” x 1/2”
screws (4 ea.), 1/4” flat washers (4 ea.) and 1/4” nuts (4 ea.).
You will need to bend the Gas Flex Lines so that the Red Plate
will reach each burner tube. Note: If it becomes necessary to
remove the Flex Line from the Red Plate, be sure to tighten the
Gas line securely to prevent any gas leaks.
4 ea. 1/4” x
1/2” Screws
4 ea. 1/4”
Nuts
4 ea. 1/4”
Washers
