Outputs (continued)
Main Outputs
(XLR)
Gain Trim
Maximum Output
THD+N (20 kHz BW @ 1 kHz)
Frequency Response
Off to 0 dB
8 Vrms
0.004%
20 Hz – 20 kHz (Flat)
Main Outputs
(RCA stereo pair)
Maximum Output Voltage
THD+N (20 kHz BW @ 1 kHz)
Frequency Response
4 Vrms
0.004%
20 Hz – 20 kHz (Flat)
Booth Outputs
(1/4”)
Gain Trim
Maximum Output
THD+N (20 kHz BW @ 1 kHz)
Frequency Response
Off to 0 dB
8 Vrms
0.004%
20 Hz – 20 kHz (Flat)
Headphone Outputs
(1/4" / 6.35 mm and 1/8" / 3.5
mm TRS)
Maximum Output Voltage
Output Power
Dynamic Range
(A-weighted)
4 Vrms (no load)
50 mW (50 ohms)
108 dB
General
Pads (16) on/off multi-color back-lit pads (8 per deck, 9 modes
each)
Wheel Displays (2) 320 x 240 Color LCD’s
Pad & FX Displays (9) 128 x 32 Monochrome OLED’s
Faders (1) MAG FOUR tension-adjustable crossfader with contour
(4) Standard channel faders
Connectors (2) XLR outputs (Main)
(2) 1/4" outputs (Booth)
(1) RCA stereo output pair (Main)
(2) XLR / 1/4” (6.35 mm) TRS inputs (Mic 1–2)
(2) RCA stereo input pairs (Deck 3–4)
(1) 1/4” (6.35 mm) TRS output (Headphones)
(1) 1/8” (3.5 mm) TRS output (Headphones)
(2) USB Type-B ports
(1) IEC power cable input
Power Connection: IEC
Voltage: 100–240 V, 50/60 Hz
Consumption: 20 W
