Ranger DST-64T User Manual

DST-64T / DST642D Wheel Balancers 76 P/N 5900192 — Rev. F — March 2021
5328019 318 Wheel Diameter Potentiometer
5328020 319 Distance Arm Slide Block
5328021 320 Wheel Distance Potentiometer
321 Distance Arm Locking Spacer
322 Nut, M8
323 Cross Recessed Tapping Screw, ST 2.9 by 9.5
5328022 324 Distance Arm Gear
325 Lock Washer
326 Snap Ring, 20 by 1
327 Distance Arm Rod Washer
5328023 328 Distance Arm Spring
5328024 329 Distance Arm Rod
330 Washer, 6 mm Flat
331 SHCS, M6 by 16
5328025 332 Distance Arm Head Connect Rod
5328026 333 Distance Arm Head Spring
5328027 334 Distance Arm Head Bushing
335 Washer, 12 mm Flat
5328028 336 Distance Arm Head Weight
5328029 337 Distance Arm Head Pivot Bushing
5328030 338 FHPS, M5 by 30 SMS
5328043 375 Distance Arm Head Assembly
5328018 380 Distance Arm Sticker

Ranger DST-64T Specifications

General

Brand	Ranger
Model	DST-64T
Category	Automobile
Language	English
