R76 Series of Tire Changers 77 P/N 5900346 — Rev. C — Dec. 2019
5327408
611
Air valve connecting link
612 Locking nut M6
613 Foot pedal (right)
614 Snap ring, φ12
615 Base board
616 Washer, φ8 Splick lock
617
HHB, M8 x 16
618
Foot pedal shaft
619
Control system adjusting pad
620
Nut, M8
621
SHCS, M8 x 50
622
Torsion spring bracket
5327035
623
Foot pedal torsion spring
624
Foot pedal limit rod
625 Foot pedal rubber insert
5327033 626 Foot pedal (left)
628 Spacer, φ6
629 Pin, φ3.2 x 25
5327038 630 Directional switch cam linkage
5400324
631
Turntable direction switch cam
632
SHCS, M6 × 12
633
Washer, φ6 splick lock
634
Washer, φ6 flat
635
Directional switch cracket
5400331
636
Directional switch, 220V/40A
637
Directional switch cover
638
SHCS, M6 x 55
5327034
639
Foot pedal return splick lock
5327745 640 Fitting, G1/8” φ8, straight
5327385 641 Jaw clamp air valve
641-1 Fitting, G1/4” φ8, straight
641-2 Silencer, G1/4”
641-3 Fitting, Tee G1/4” φ8
642 Spacer, φ8
643
Washer, φ8 splick lock
644
SHCS, M8 x 20
5327386
645
Bead breaker air valve
645-1
Fitting, G1/4" φ10
645-2
Fitting, Tee G1/4” φ8
646
Cylinder retaining bush
648
Washer, φ5 flat
649
Washer, φ5 splick lock
