R76 Series of Tire Changers 85 P/N 5900346 — Rev. C — Dec. 2019
5327098
842
L/R assist arm valve cover
842-1 Assist arm valve control assembly
843 Assist arm control valve
5401427 844 Banjo bolt, G1/8" φ6 single
5401427 844 Banjo bolt, G1/8" φ6 single
846 Assist tower bent arm
846-1
Metal braided hose cover
847
Adjustment silencer, G1/8”
848
Fitting, φ6 x 1/8" 90°
849
Nut, M8
850
O-ring, 16 x 2.4
851
Cylinder front flange
851
Cylinder front flange
852
O-ring, φ25 x 2.65
852 O-ring, φ25 x 2.65
853 O-ring, φ90 x 2.65
854 Left assist tower cylinder rod
854 Left assist tower cylinder rod
855 Assist tower cylinder piston
855
Assist tower cylinder piston
856
O-ring, φ14 x 2.4
856
O-ring, φ13.2 x 2.65
857
Y-ring, φ82.5 x 5.3
858
Locking nut, M12
859
Cylinder connecting thread shaft
860
Left assist tower cylinder body
860
Left assist tower cylinder body
5327388
860-1
Left assist tower cylinder
5327429 861 Assist tower rear cylinder plate
862 Seal ring, φ33 x 25 x 6
862 Seal ring, φ35 x 25 x 8
863 Bearing B3025
864 Assist arm handle weldment
865 Cross recessed pan head screw, M5 x 12
866
Washer, φ5 flat
867
Washer, φ5 splick lock
868
SHCS, M10 x 20
869
Washer, φ10 flat
870
Spring
871
Nut, M4
872
Washer, φ 4 flat
873
Washer, φ 4 splick lock
