R76 Series of Tire Changers 86 P/N 5900346 Rev. C — Dec. 2019
874
Cross recessed pan head screw, M4 x 12
875 Washer, φ12
877 Washer, φ12
878 8 mm to 6 mm union
5530061 879 SHCS, M12 x 25
880 Washer, φ12 splick lock
881
Washer
882
Roller latch, M8 x 18
883
Cone shaft
5400890
884
Assist arm cone
5327979
885
Assist tower bent arm plug
5327582
886
Presser arm weldment
5328283
887
Black assist top knob
888
Nut, M18
5328279 889 Screw
5327075 890 Assist arm block
891 Nut, M6
5400959 892 SHCS, M6 x 30
5327173 893 Tool box
893-1
Washer, φ8 flat
893-2
SHCS, M8 x 20
893-3
Washer, φ8 splick lock
893-4
Washer, φ8 flat
893-5
SHCS, M8 x 25
893-6
Washer, φ8 splick lock
893-7
Tool box bracket
893-8
Nut, M8
