SPECIFICATIONS 12
12.1 ENGINE SPECIFICATION ______________________________________________
Model: V2403-CR-TE5
Type: Vertical, water-cooled, 4-cycle diesel engine
Number of Cylinders 4
Bore and Stroke 87mm x 102.4mm (3.43 in. x 4.04 in.)
Total Displacement 2.434 litres (148.53 cu.in.)
Combustion Type Direct Injection
SAE Net Intermittent kW / rpm
H.P. (SAEJ1349) (HP / rpm)
48.6 kW @ 2700 rpm
(65.2 HP @ 2700 rpm)
Maximum Torque / Rotating Speed
198.5 N-m / min (1600 rpm)
20.2 kg-m / min (1600 rpm)
Maximum Bare Speed: 2850 ± 50 rpm
Idle Speed: 1400 ± 100 rpm
Firing order 1-3-4-2
Direction of Rotation Counter-clockwise (viewed from flywheel side)
Compression Ratio 18.1
Fuel: Diesel to BS EN590 or ASTM D975 (Ultra Low Sulfur)
Lubrication (API Class) Above CJ4
Dimensions
(length x width x height)
869mm x 517mm x 735mm
(34.2 in. x 20.4 in. x 28.9 in.)
Dry Weight
(BB Spec.)
233kg (513 lbs)
Starter Cell starter
Starter motor 12V, 2.0kW
Generator 12V, 480w
