4
1. APPLICATION AND DEVICE CODE MEANING
The device is stationary-type equipment intended for storing and expose food
products (previously cooled) at a reduced temperature. Unpacked food should be
stored (exposed) in containers or on trays specially designed for this purpose.
DEVICE CODE MEANING
Example of device code:
L-F Max/202/107/2N
L – type of the device: refrigerated counter
E, E Max, E1, E1 Max, F, F Max – device model
2N – housing made of stainless steel
202/107 – device dimensions (see table p.2)
Important information on the rating label of each device:
In the case of contact with the service
department, prepare the following data for
efficient service:
device type,
serial no. of device
Climatic class means the maximum ambient
temperature at which the device works without
disturbances.
3
maximum permissible ambient temperature
of +25°C,
temperature test:
ambient temperature +25°C ± 1°C
relative humidity 60% ± 3%
Name, logo and device type
Device technical parameters
Manufacturer contact details
