RAPA E - 6. DRAWINGS; Fig. 1: Back View; Fig. 2: Side View; Fig. 3: Product Layout

7
6. DRAWINGS
Fig. 1
Fig. 2.
Fig. 1 Back view
Fig. 2 Side view
Fig. 3 Layout of products in enlarged storage of L-E Max, L-E1 Max i L-F Max counters.
Fig. 3
Do not block the air outlet with products.
Place the goods on the platform.
Defrost water collection drain
Aggregate cover
Aggregate switch
Lighting and backlight switch
products
depth with open door
depth
length
products
Electronic temperature controller
Enlarged storage
Standard storage
