Rapsodo HITTING 2.0 User Manual

DEVICE PLACEMENT AND SETUP
10
1.
Internal Tank Set-Up
1.1. Attach monitor to mount plate.
1.2. Place RCE in housing.
1.3. Connect USB from monitor to RCE.
3.
Calibration
3.1. Align monitor angles with help of the application.
3.2. Use azimuth view and tape measure to position the tank directly
in the center of home plate.
NOTE: Rapsodo HITTING 2.0 operates in a tank. Correct positioning is important to get accurate results.
2.
Tank Positioning
2.1 Rapsodo HITTING 2.0 should be placed 14’ from the front of home
plate and the camera opening should face the batter.
2.2 The tank should be placed on an even surface and SHOULD NOT be
used in the rain or wet conditions.
Rapsodo HITTING 2.0 should only be used at the designated distance
and on a flat surface. Improper placement may cause injury.
14’
