27
Technical Specification - Rascal Frontier Scooter
Wheelchair type Class Class A, B or C Class C
D
epartment of Transport Class Class 1 2 or 3 Class 3
Overall dimensions fully assembled length x width x height mm (in) 1430 (56) x 650 (26) x 1020 (40)
Dimensions seat removed tiller folded length x width x height mm (in) 1430 (56) x 650 (26) x 730 (29)
M
aximum carrying capacity at 7˚ incline* kg (lb) 136 (300)
Maximum carrying capacity at 10˚ incline* kg (lb) 106.5 (235)
Mass (weight) including batteries (55Ah) kg (lb) 99.5 (219.3)
B
attery voltage and maximum capacity volts and ampere hours 12V 55Ah x 2
Type of seat Captain (regular) Swivel, folding back & arms
with width adjustment.
Mass (weight) of seat kg (lb) 14.5 (32)
Wheel size front/rear mm (in) Front wheel 260 x 76 (10 x 3)
Rear wheel 291 x 76 (11 x 3)
Type of tyres type Pneumatic
Tyre Pressures normal front/rear p.s.i. (bar) 36 (2.48) / 36 (2.48)
Maximum speed km/h (m.p.h.) 12.9 (8)
Minimum braking distance from maximum speed metres (feet) 3.2 (10.5)
Range on full charge and flat ground km (miles) Up to 40 (25)
The turn-around width m (ft) 1.4 (4.6)
The maximum safe slope degrees of slope 10˚ & 7˚- see carrying capacity* - Do not
exceed - the scooter may topple
The maximum climbing ability facing upwards degrees of slope 10˚ at 235lbs - see max carrying capacity*
7˚ at 300lbs - see max carrying capacity*
Ground clearance mm (in) 90 (3.5)
Maximum obstacle climbing ability mm (in) 100 (4)
Maximum safe descendable kerb height mm (in) 100 (4)
