Technical Specification - Rascal Pioneer Scooter
Wheelchair type Class Class A, B or C Class C
D
epartment of Transport Class Class 1 2 or 3 Class 3
Overall dimensions fully assembled length x width x height mm (in) 1470 (58) x 645 (25) x 1300 (51)
Dimensions seat removed tiller folded length x width x height mm (in) 1470 (58) x 645 (25) x 730 (29)
M
aximum carrying capacity kg (lb) 159 (350)
Mass (weight) including batteries kg (lb) 130 (286.6)
Battery voltage and capacity volts and ampere hours 12V 75Ah x 2
T
ype of seat Captain (enhanced) Swivel, head rest, reclining/folding back
& arms with width adjustment and seat
slide function.
Mass (weight) of seat kg (lb) 18 (39.6)
Wheel size front/rear mm (in) 305 x 76 (12 x 3) / 305 x 76 (12 x 3)
Type of tyres type Pneumatic
Tyre Pressures normal front/rear p.s.i. (bar) 36 (2.48) / 36 (2.48)
Maximum speed km/h (m.p.h.) 12.9 (8)
Minimum braking distance from maximum speed metres (feet) 3.2 (10.49)
Range on full charge and flat ground km (miles) Up to 56 (35)
The turn-around width m (ft) 1.8 (5.8)
The maximum safe slope degrees of slope 10˚ - Do not exceed the scooter may topple
The maximum climbing ability facing upwards degrees of slope 10˚
Ground clearance mm (in) 90 (3.5)
Maximum obstacle climbing ability mm (in) 100 (4)
Maximum safe descendable kerb height mm (in) 100 (4)
