• Remove the battery packs by carefully lifting
each one clear of the scooter chassis. (Fig 17)
Warning, these parts are heavy!
• Remove the shopping basket by lifting /
sliding up. (Fig 18)
• Lock the steering position by pulling and
then twisting the transport tiller lock knob with
the wheels pointing straight forwards. (Fig 19)
• Fold the tiller unit down by first loosening
the tiller securing thumb-wheel, lower the tiller to
the desired position and re-tighten the thumb-wheel
(Fig 20).
• Separating the chassis The two halves of the
chassis can also be split apart to make transpor-
tation more easy. To do this, raise the transaxle
release handle with one hand. With the other hand
grasp the handle at the rear of the scooter and pull
which will separate the front and rear halves. (Fig
21) Be careful not to pinch your fingers between the
two halves of the chassis
• Safely stow the component parts in the boot
of the car.
15
19
18
16
20
17
21
Warning! Do not attempt to lift any of the
scooter components unless you are capable
of doing so. The weight for each component is
shown in the Technical Specification.
Warning! Do not attempt to lift the chassis
unassisted - back or other injury may result!
