Rascal Vista and Vista DX Scooters Owner’s Manual and Service Record
Technical Specification - Rascal Vista DX Scooter
Wheelchair type Class Class A, B or C Class B
Department of Transport Class Class 1 2 or 3 Class 2
Overall dimensions fully assembled length x width x height mm (in) 1180 (46.5) x 585 (23.0) x 1150 (45.27)
Dimensions seat back and tiller folded length x width x height mm (in) 1180 (46.5) x 585 (23.0) x 860 (33.85)
Maximum carrying capacity kg (lb) 140 (308.65)
Mass (weight) including 50 Ah batteries kg (lb) 86.2 (190)
Mass (weight) of heaviest part kg (lb) Front chassis 25 (55.12)
Mass (weight) of battery packs x 2 kg (lb) 16.7 (36.81) x 2 = 33.4 (73.63)
Maximum shopping basket load kg (lb) 4.5 (9.9)
Standard battery voltage and capacity Volts and Ampere hours 12V / 50Ah x 2
Type of seat Captain’s seat with folding backrest, headrest and adjustable arms.
Integrated swivel and slide functions.
Mass (weight) of seat kg (lb) 14.2 (31.3)
Wheel size front & rear mm (in) 230(9) × 75 (3) × 50 (2)
Type of tyres Solid foam filled - puncture proof
Suspension Type Front and rear - coil sprung
Maximum speed km/h (m.p.h.) 6.4 (4)
Minimum braking distance from maximum speed m (ft) 1.77 (5.8)
Range* km (miles) Up to 55.52 (34.5)
The turn-around width m (ft) 1.7 (5.8)
Turning radius m (ft) 1.5 (4.9)
The maximum safe slope degrees of slope 6˚ - Do not exceed the scooter may topple
The maximum climbing ability facing upwards degrees of slope 6˚
Ground clearance mm (in) 75 (3)
Maximum obstacle climbing ability mm (in) 60 (2.36)
Maximum safe descendable kerb height mm (in) 60 (2.36)
Force to operate Accelerator control Newtons (lbs) 2.5 (0.55)
Force to operate Freewheel lever Newtons (lbs) 58.8 (13.2)
Ambient operating temperature range °C (°F) 2 (35.6) to 40 (104)
Note: Pneumatic Tyre Option. This vehicle can be supplied with pneumatic tyres - Ask your Dealer for details.
This scooter meets the relevant requirements of ISO 7176:14 2008 *Range on full charge and flat ground. Due to a policy of
continual improvement, Electric Mobility Euro Ltd. reserves the right to change specifications without prior notice.
