Raspberry Pi 4 b Installation Guid

Dependent on intended usage the following ports can / should be connected;
Micro HDMI
AUDIO
Ethernet
USB2.0 and USB3.0 ports
DSI Display (for use with Official Raspberry Pi display, sold separately)
CSI Camera (for use with Official Raspberry Pi Camera module, sold separately)
Any external power supply used with the Raspberry-Pi shall comply with relevant regulations and
standards applicable in the country of intended use.
At no point should any part of the board be altered as this will invalidate any existing compliance
work. Always consult professional compliance experts about integrating this module into a product
to ensure that all certifications are retained.
4. Antenna Information
The antenna on board is a Dual band (2.4GHz and 5GHz) PCB niche antenna design licensed from
Proant with Peak Gain: 2.4GHz 3.5dBi, 5GHz 2.3dBi. It is important that the antenna is placed in a
suitable place inside the product to ensure optimal operation. Do not place close to metal casing.
USB3.0
USB2.0
DISPLAY
ETHERNET
Micro HDMI
CAMERA
AUDIO
Micro HDMI
USB-C Power

Raspberry Pi 4 b Specifications

General

Processor	Broadcom BCM2711, Quad core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz
RAM	2GB, 4GB, or 8GB LPDDR4-3200 SDRAM (depending on model)
Ethernet	Gigabit Ethernet
Video Output	2 × micro-HDMI ports (up to 4Kp60 supported)
Storage	MicroSD card slot for operating system and data storage
GPIO	40-pin GPIO header
Power Supply	5V DC via USB-C connector (minimum 3A*)
Wireless	2.4 GHz and 5.0 GHz IEEE 802.11ac wireless, Bluetooth 5.0, BLE
USB Ports	2 × USB 3.0 ports, 2 × USB 2.0 ports
Audio Output	3.5mm audio jack
Operating Temperature	0 – 50 °C
GPU	VideoCore VI graphics
Power Options	USB-C or GPIO header
