Rattler 369D - harness and wire identification

8
© 2003 directed electronics, inc.
pprriimmaarryy hhaarrnneessss ((HH//11)),,
99--ppiinn ccoonnnneeccttoorr
sseeccoonnddaarryy hhaarrnneessss ((HH//22)),,
66--ppiinn ccoonnnneeccttoorr
HH11//11
HH11//22
HH11//33
HH11//44
HH11//55
HH11//66
HH11//77
HH11//88
HH11//99
LT. GREEN/BLACK Factory Alarm Disarm
WHITE/BLUE (-) Activation Input
GREEN/WHITE Factory Alarm Rearm
YELLOW Ignition Output (to alarm)
GRAY/BLACK (-) Wait to Start Input
WHITE/RED (+) Activation Input
RED/WHITE Channel 2 (output)
BLACK Ground
HH22//11
HH22//22
HH22//33
HH22//44
HH22//55
BLACK/WHITE (-) Neutral Safety Switch Input
GRAY (-) Hood Pinswitch Shutdown Wire
VIOLET/WHITE Tachometer Input
BROWN (+)Brake Switch Shutdown Wire
BLUE/WHITE (-) 200 mA 2nd Status/Rear
Defogger Output
WHITE (+/-) Light Flash
