INSTRUCTION, USE AND
MAINTENANCE MANUAL
1
2
3
4
5
6
7
8
10
11
11
12
13
14
15
9
G2.124R - GP2.124R
RAVAGLIOLI S.p.A.
1297-M010-0_R
KEY
1 – Weight holding bridge
2 – Pneumatic mandrel (only for GP2.124R model)
3 – Distance-diameter caliper
4 – Threaded mandrel (only for G2.124R model)
5 – Protection guard
6 – Foot brake (only for G2.124R model / pneumatic mandrel open-close pedal (only for GP2.124R model)
7 – Main switch
8 – External data gauge (optional)
9 – Grippers for weight fitting
10 – Display with keyboard
11 – Pusher ring
12 – Rapid ring nut (only for G2.124R model)
13 – Locking sleeve (only for GP2.124R model)
14 – Cones
15 – Professional external data gauge (optional)
Fig. 1 - G2.124R - GP2.124R
