INSTRUCTION, USE AND
MAINTENANCE MANUAL
17.0 SPLIT PROCEDURE
The Split procedure proves useful when the dynamic
unbalance (see Par. 15.3.1) of a wheel is fairly high and
the weight to be fitted is not available, for instance a
100 g weight. It's possible then to correct the unbal-
ance dividing the amount of weight into two weights
of smaller size.
The Split procedure eliminates errors caused by manu-
ally fitting two 50 g weights close to one another, which
could leave considerable outstanding unbalance.
For example:
100 g WEIGHT
TO BE FITTED TO CORRECT UNBAL-
ANCE
TWO SMALLER WEIGHTS (50g)
FITTED MANUALLY
Fig. 75
1
2
Balancing procedures are identical for both modes
(car/motorbike).
By selecting motorbike, besides dynamic balancing
(see Par. 15.3.1) STATIC balancing and/or ALU-S (see
Par. 15.3.3 and/or 15.3.4) can also be performed by
pressing “F2 key” from the initial page.
G2.124R - GP2.124R
RAVAGLIOLI S.p.A.
1297-M010-0_R
