Ravaglioli KPH 363 A Series User Manual

20
0483-M003-1
1 COLONNE DE COMMANDE
2 COLONNE OPPOSEE
3 CHARIOTS
4 BRAS
5 BOITIER DE COMMANDE
6 MOTEUR CENTRALE
HYDRAULIQUE
1 COLONNA COMANDO
2 COLONNA OPPOSTA
3 CARRELLI
4 BRACCCI
5 SCATOLA COMANDO
6 MOTORE CENTRALINA
IDRAULICA
1 CONTROL POST
2 OPPOSITE POST
3 CARRIAGES
4 ARMS
5 CONTROL BOX
6 HYDRAULIC CONTROL
UNIT MOTOR
1 STEUERSÄULE
2 NEBENSÄULE
3 HUBWAGEN
4 ARME
5 SCHALTSCHRANK
6 MOTOR DER HYDRAULIK-
ZENTRALE
1 COLUMNA DE MANDO
2 COLUMNA OPUESTA
3 CARROS
4 BRAZOS
5 CAJA DE MANDO
6 MOTOR CENTRAL HI-
DRÁULICA
1
3
2
5
4
4
6
4
