8.12 Summary of TEST and ADJUSTMENT data
This display page appears when all vehicle adjustments have been made.
Figure 38
SENS. KEYBOARD
PC KEYBOARD
DESCRIPTION
Operations finished ! Client
data entering
(para. 8.14 page 35)
Displays vehicle technical
data page
(para. 8.3 page 23)
Displays an options menu
[para. 8.13 a page 34)
Repeat adjustment
operations
(para. 8.10 page 31)
Summary of test
data
Summary of
adjustments
made
